SPS
Model | SPS 01 | SPS 02 | SPS 03 | SPS 04 | SPS 05 |
Flowrate (cc/min) | 60 | 90 | 120 | 150 | 200 |
Max Pressure (Bar) | 3 | 3 | 3 | 3 | 2 |
Authentication |         | ||||
Application Area | Steam iron, steam brush, hanging iron, steam floor mop, cleaner, stage hood | ||||
Category:
Ironing series
Keywords:
- Product Description
- 参数概要
-
Design Drawing：
An optional water outlet nozzle is available
SPECIFICATIONS (SPS 0X) Model SPS 01
SPS 02
SPS 03
SPS 04
SPS 05
Noise(dB) 50
Power(W) 16W
Duty Cyle Continuously
Voltage 220-240V / 50Hz、120V / 60Hz、220V / 60Hz、100V / 50-60Hz、12-36V / 50Hz
PROUCT INFORMATION Pump Desing Solenoid Pump Insulation Class H Weight 110g Outlet Connector Barb port/Thread LABORATORY TEST CONDITION 1.5min ON/1min OFF Ta 60℃、Tf 35℃ Ta:Ambient temperature
Tf:Temperature of fluid water
Self-priming at 0 Bar except SV Type Note:All the preformance are intended with a tolerance ±10% Water 20℃ Ambient 25℃
-
Model
SPS 01
SPS 02
SPS 03
SPS 04
SPS 05
Flowrate (cc/min)
60
90
120
150
200
Max Pressure (Bar)
3
3
3
3
2
Authentication
Application Area
Steam iron, steam brush, hanging iron, steam floor mop, cleaner, stage hood
